(超值優惠歡迎洽詢) 華碩 Pro E500 G6 低階繪圖工作站【Intel Core i5-10500 / 8G*1 DDR4-3200 / 1TB硬碟 / NO OS】

中央處理器

Intel Core i5-10500
支援單顆 Intel®處理器

晶片組

Intel® W480 Chipset

作業系統

無內建作業系統

記憶體

含8G記憶體*1 DDR4-3200 (非陸製) (因CPU頻率支援實際運行為DDR4-2666)

記憶體插槽數量/已佔用數量

總 Slots 數 : 4 (2 通道) 總容量 : 最大至 128GB UDIMM 記憶體類型 : 雙通道 DDR4 2933/2666 non ECC and with ECC 記憶體大小: 32GB, 16GB, 8GB UDIMM

硬碟機

1TB (非陸製)

硬碟機數量(標準/最大)

1x internal 2.5” drive bay 3x internal 3.5” drive bay (or 3x internal 2.5” drive bay: optional cage required) 2x internal 2.5”/3.5” drive bay (optional cage required)

光碟機

DVD-RW

磁碟控制器

SATA 控制器: Intel® W480 Chipset 8 x SATA3 6Gb/s 連接埠 Intel® Rapid Storage Technology(RST) (For Windows Only) (Support Software RAID 0, 1, 5, 10 )

顯示晶片

CPU Integrated (Intel UHD) Multi-VGA output support: DVI-D/HDMI/DisplayPort/VGA - Supports DVI-D with Max resolution 1920 x 1200@60 Hz - Supports HDMI 1.4 with Max resolution 4096 x 2160@24 Hz - Supports DisplayPort 1.2 with Max resolution 4096 x 2304@60 Hz - Supports VGA with Max resolution 1920 x 1200@60 Hz

I/O傳輸介面

前面板: 2 x USB 3.2 Gen1 2 x USB 2.0 1 x Headphone port 1 x Microphone port
後面板: 2 x USB 3.2 Gen2 ports (1 port at Type A, 1 port at Type C) 4 x USB 3.2 Gen1 ports 1 x HDMI 1 x DisplayPort 1 x DVI-D 1 x VGA 2 x RJ-45 ports 1 x 7.1-channel Audio I/O ports (5 + 1 Audio jacks)

網路功能

1 x Intel® I225-LM 2.5GbE LAN (2.5G) 1 x Intel® I219-LM Gigabit LAN

擴充槽數量

Total: 6 Location-1: PCIe x1 slots (Gen3 x1 link, FH, FL)* Location-2: PCIe x16 slots (Gen3 x16/x8 link, FH, FL) Location-3: PCIe x1 slots (Gen3 x1 link, FH, FL)* Location-4: PCIe x16 slots (Gen3 x0/x8 link, FH, FL) Location-6: PCIe x16 slots (Gen3 x4 link, FH, FL) Location-7: PCIe x16 slots (Gen3 x4 link, FH, FL)** *the bandwidth of PCIe link is shared with M.2_1 ** the bandwidth of PCIe link is shared with 4 x SATA ports

尺寸/其他

•423mm x 190mm x 435mm
•300W 80PLUS Single Power Supply, Bronze Rating:100-127/220-240V, 6/3A, 60-50Hz, Class I
•內建IC卡讀卡機 USB 鍵盤及滑鼠
•3-3-3(零件/人工/隔日到府)
